Alpha one
STREAMING INTEGRATED AMPLIFIER
Alpha One is the result of the experience gained during the development of our Reference line and
represents a synthesis of B.audio’s technological know-how. The goal was both simple and demanding: combine
a cutting-edge DAC together with a high-end passively cooled dual-mono amplifier in a single enclosure.
Our proprietary EX networking module is also included, offering acoustic correction and advanced streaming capabilities.
State-of-the-art digital playback
The B.audio Alpha One benefits from B.audio’s patented SJR « Source Jitter Removal » technology.
By completely eliminating the jitter from any digital source, it allows the conversion circuits to work optimally,
ensuring unprecedented digital-to-analog conversion quality, regardless of the digital input format.
The result is a realistic, rich and lively sound. Combined with the embedded EX network module,
this is the key to an unparalleled streaming music experience.
Extended bandwidth preamplification
The preamp stage of the Alpha One relies on a fully symmetrical construction, featuring
a relay driven resistor network volume control for a perfect balance between the left and right channels.
No coupling capacitor is mounted in the Alpha One. Operating outside the signal path,
multi-pole servo circuits are used to provide a constant continuous reference to the active elements
of the circuit. The integrity of the audio signal is thus fully preserved, ensuring a high level of
transparency together with an extreme bandwidth extension, refined highs and extremely deep bass.
Dual-mono internal construction
The amplifier stage of the Alpha One is directly derived from our reference power amplifiers.
Its in-house refined topology was designed to drastically reduce dynamic distortion.
Optimizing the use of local feedback at the most critical stages, it benefits from the advantages of a class AB
output stage while maintaining a perfect linearity of operation. Its dual mono design features
comfortable power ratings together with a high current reserve, allowing it to drive
the most demanding loudspeakers with powerful bass handling.
SPECIFICATIONS
GENERAL |
||
Power supply | Factory set: 220-230V or 100-115V, 50-60Hz | |
Dimensions | 450x395x102mm | |
Weight | 15.5kg | |
Output power | 120W under 8 ohms 200W under 4 ohms |
|
Bandwidth | > 200kHz | |
THD | < 0.001% (1-100W, 8ohm) |
|
DIGITAL SECTION |
||
D/A Conversion | Multibit sigma-delta | |
DAC Clock management | Patented SJR technology | |
Streaming protocols | UPnP, MPD, LMS, NAA, Roon, Airplay Gapless playback Access to streaming services (Qobuz, Tidal, Spotify, …) via compatible iOS and Android applications |
|
Integrated music server | UPnP / Openhome | |
Acoustic correction | 64-bit DSP, 8x parametric filters with automatic gain adjustment | |
Inputs | 1x SPDIF (PCM up to 24bits / 192kHz) 2x Toslink (PCM up to 24bits / 96kHz) 1x AES/EBU (PCM up to 24bits / 192kHz) 1x USB type B (PCM up to 384kHz / DXD / DoP / native DSD up to DSD 256) 1x RJ45 (PCM up to 384kHz / DXD / DoP / native DSD up to DSD 256) 1x USB DATA (to connect a storage media / SSD disk) |
|
PRE-AMPLIFICATION | ||
Volume control | Analog, via switched resistor network, -80 to +0dB, 64 steps | |
Construction | 100% balanced | |
Inputs | 1x XLR (balanced) 2x RCA (unbalanced), one of which configurable as bypass (Home Theater use) |
|
Input impedance | 47 kOhm | |
Pre-out | 1x XLR (balanced) | |
Output impedance | 100 Ohm | |
AMPLIFICATION | ||
Construction | Dual-mono, class AB, passive cooling (fanless) | |
Output stage | 2 pairs of high current bipolar transistors | |
Speaker connectors | Universal, compatible with forks, bare cables and banana plugs |
